EPLAN Pro Panel: Virtual Cabinet Layout in 3D
EPLAN Pro Panel is a CAE engineering software focusing on the design of three-dimensional control cabinet and switch cabinet. The functions provided by the software mainly include: three-dimensional layout design in electric or fluid control cabinet; virtual three-dimensional wiring or piping; automatic generation of data required for NC machining; data provision for cable pre-assembly and automatic cable processing; design of three-dimensional distribution bus system and bending copper bar; and complete integration with production and manufacturing process, etc. The innovative EPLAN platform integrates electrical and fluid engineering design with the design, production and assembly process of three-dimensional control cabinet. Fully consistent data can greatly improve the quality of the project and accelerate the whole project process.
Rational Planning
EPLAN Pro Panel demonstrates its professionalism from many perspectives, such as dynamic interference checking, automatic adaptation of installation specifications, and so on. At the beginning of cabinet design, the components to be assembled are presented centrally in navigator and assembly list. Simply drag them into the 3D cabinet. The unique eTouch technology provided by the software enables you to place and align the components more easily and accurately. Some components require minimum installation clearance during installation, or special installation specifications, and the software will be fully considered and evaluated. All of these are just for you to plan and place slots, guideways, bus systems and other equipment more reasonably!
Flexible layout
Based on the structure of three-dimensional layout, EPLAN Pro Panel can automatically generate virtual three-dimensional wiring by reading the definition and connection information of wiring network from the schematic diagram. The software automatically evaluates the optimal routing path and automatically detects the slot fullness of the slot. Automatic calculation of cable length will greatly improve productivity, manual calculation of cable length is time-consuming and laborious, and error-prone. The advent of EPLAN Pro Panel will make all of this become a yellow flower tomorrow!
Quick Start
No equipment data in engineering design? Unbelievable! EPLAN Pro Panel provides users with a variety of access to device data - device data also includes 3D geometric data. Device data can be directly accessed from EPLAN Data Portal, imported with built-in STEP interface, retrieved from manufacturer, or retrieved from data CD or 3D CAD program. After reading the data to the EPLAN Pro Panel, it can quickly convert to the EPLAN macro required for 3D layout. Appendix management in EPLAN has been perfectly close to the needs of users. Users can also store their technical data and allowable assembly combinations when storing system components and accessories.
Data consistency
EPLAN software platform, which integrates schematic design and three-dimensional layout design closely, can directly use the equipment selected in electrical engineering design when three-dimensional layout. There is no duplicate data creation, no data back-and-forth transmission, and no multiple synchronization and consistency checks. Thus, designers of all disciplines will benefit from real-time data consistency.
EPLAN platform is open and flexible. It has built-in multiple data interfaces. It can be integrated with your company's various management systems for direct data transmission. Not only do project engineers benefit from this, but people in business or production can also benefit from data consistency.
Top-level process optimization
Control cabinet design is not isolated from other engineering disciplines, independent of the world? Consistent product development processes will simplify your work: repetitive data storage, repetitive rework and changes will never come back.
Direct Production Processing
EPLAN Pro Panel can directly provide the machining data of mounting plate, door or whole cabinet. All kinds of information needed for production, such as drilling, tapping and milling grooves, can be transmitted directly to the CNC machining center for production and processing. EPLAN Pro Panel even provides several standard NC (Data Processing) plug-ins, with which processing data can be directly provided to STEINHAUER and KEISLING machine tools. Of course, EPLAN Pro Panel can also provide standard DXF files for other machine tools or manual production!
Rapid Processing of Cables and Cables
When EPLAN Pro Panel is used for design, the production and processing of cables will become simpler and faster. Whether manually or automatically produced, all kinds of data related to cables can be directly provided by software. These information can be output in intermediate formats (such as TXT, CSV, etc.) or directly to the automated cable processing machine.
A quick overview of added value
EPLAN Pro Panel provides customers with continuous, optimized design support and outstanding integrated manufacturing solutions. Relatively speaking, it means shorter production cycle, less cost and higher product quality.
EPLAN-eTouch Technology in Twin 3D Design-Layout Design as Simple as 2D
Twin attachments can be easily configurable and automatically positioned-page-by-page look at the sample has become a thing of the past
Convenient design comes from intelligent design aids
Consideration of product technical specifications by twin software ensures reliable design
Twin on-line interference checking and error detection can ensure high quality
Optimal size and space utilization help reduce costs
Direct control of NC machine tools by twins to ensure accurate assembly of components
Twin virtual wiring can be used for accurate cable pre-processing and rapid assembly.
Other benefits of using EPLAN solutions
Completely consistent software appearance and operation
Basic EPLAN Technology and Idea Same
Direct utilization of project resources
0 Through EPLAN Data Porta
